Reliable Sc200-200 Heavy Duty Construction Lift for High-Rise Projects
Reliable Sc200-200 Heavy Duty Construction Lift for High-Rise Projects
Reliable Sc200-200 Heavy Duty Construction Lift for High-Rise Projects
Reliable Sc200-200 Heavy Duty Construction Lift for High-Rise Projects
Reliable Sc200-200 Heavy Duty Construction Lift for High-Rise Projects
1 / 5
Reliable Sc200-200 Heavy Duty Construction Lift for High-Rise Projects
Reliable Sc200-200 Heavy Duty Construction Lift for High-Rise Projects
Reliable Sc200-200 Heavy Duty Construction Lift for High-Rise Projects
Reliable Sc200-200 Heavy Duty Construction Lift for High-Rise Projects
Reliable Sc200-200 Heavy Duty Construction Lift for High-Rise Projects

Reliable Sc200-200 Heavy Duty Construction Lift for High-Rise Projects

Customization: Available
After-sales Service: Oversea
Warranty: One Year
Send Inquiry

Product Description

Basic Specifications

Model NO.
SC200/200
Load Capacity
1t / 2000kg
Speed
40M/Min - 60M/Min
Usage
Construction Hoist
Sling Type
Wire Rope
Lift Drive
Electric Motor
Lift Mechanism
Lift Chain
Elevator Door
Sider Door
Package
Container
Origin
China
HS Code
8428909090
Capacity
1000 Pieces/Year

Technical Parameters

Parameter Name Unit SC200/200 Frequency Hoist
Height m 300
Rated load kg 2000/2000
Lifting speed m/min 0-40 / 0-45 / 0-55 / 0-66
Electromotor Model - YZEJ132M(L)-4
Power kw 15×2 / 11×3 / 15×3 / 18.5×3
Speed-limiter Model - SAJ40-1.2A / SAJ40-1.4
Tripping Speed m/s 1.2/1.4
Mast section dimension mm 650×650×1508
Crane cage inner net dimension m 3.0×1.3×2.2 / 3.2×1.5×2.2
Safe and protection system Upper/below limited switches, falling avoiding device, gate safe lock, overload safety device, etc.

Main Features

The maximum design height reaches 400m with variable frequency adjustment speeds up to 96m/min.
Complete safety design including progressive anti-dropping devices and reliable automatic compensation disc brakes.
External drive device that operates independently with flexible buffers for stable running and braking (Patented structure).
Integrated folding ladder inside the cage to save space during operation (Patented design).
Pioneering dipping paint process ensures total coverage and significantly improves corrosion resistance and service life.
Optional floor calling device for automatic stopping at up to 30 floors with one-button operation.
Heavy Duty Construction Lift
SC200 Construction Hoist Detail
Construction Lift Structure

Frequently Asked Questions

What is the maximum lifting height and speed of the SC series?
The maximum design height is 400 meters, and with variable frequency adjustment, the speed can reach up to 96m/min.
How is the safety of the hoist ensured during operation?
The hoist is equipped with a progressive anti-dropping safety device, electromechanical interlocking on cages and guardrails, and automatic compensation disc brakes.
What is the load capacity of the SC200/200 model?
The rated load capacity for each cage is 2000kg (2 tons), making it suitable for heavy-duty construction projects.
Does the hoist have corrosion protection?
Yes, it utilizes a pioneering dipping paint process that eliminates dead angles in the standard section coating, greatly enhancing corrosion resistance.
Can the hoist stop automatically at specific floors?
Yes, by configuring a floor calling device, the hoist can support automatic stopping for up to 30 floors.
